Code of conduct for safe operation of asphalt mixers

With the strengthening of the trend of environmental protection and energy conservation, the environmental protection of asphalt mixing plants has gradually become the mainstream form of mixing plant development. What kind of equipment can be called an environmentally friendly asphalt mixing plant? What are the basic conditions that must be met?
First of all, as an environmentally friendly asphalt mixing plant, it must meet the requirement of using less energy consumption during use. That is to say, under the conditions of the same quantity and quality, less energy is consumed during the operation process, including various resources such as water and electricity.
Secondly, environmentally friendly asphalt mixing plants not only require less energy consumption, but also must achieve higher production efficiency, while also reducing carbon emissions in the entire production process, so as to meet the proposed low-carbon production requirements.

Construction safety has always been a major issue, and we cannot let any safety hazard go unnoticed. Especially the use of equipment at the construction site. Asphalt mixing stations are prone to failure. Strengthening the maintenance of this equipment is essential to ensure safe construction at the construction site, improve equipment integrity, reduce equipment failures, and ensure the quality of concrete. The role of neglect.
The composition of the asphalt mixing plant is relatively complex, so during maintenance, classified maintenance should be carried out according to the usage and functions of different parts. Maintenance content can be divided into tank maintenance, winch system maintenance and adjustment, stroke limiter adjustment and maintenance, wire rope and pulley maintenance, lifting hopper maintenance, track and track bracket maintenance, etc.

The renovation of the combustion-supporting system of the asphalt mixing plant and the use of DC frequency conversion CNC machining technology are all renovations of the original system. In addition to the above renovation plans, with the existing equipment and personnel, what other measures can be taken in the application to reduce the operating costs of concrete mixing plants?
At present, China has no mandatory national industry standards for heavy residual oil, and the quality of fuel oil varies greatly. Even from the same dealer, the quality difference between batches is very large, and it contains more residues. Therefore, bridge inspection equipment should be installed on the construction site, and professional personnel should inspect various performance parameters of gasoline and diesel to strictly control quality.
When the burner is working, if the flame of the combustion aid is red and the smoke from the ash removal chimney is black, this is the manifestation of poor atomization of gasoline and diesel and insufficient combustion aid. At this time, the following measures should be taken to deal with it: properly adjust the distance between the nozzle and the vortex plate, generally push it inward to a suitable distance, the purpose is to prevent the atomized oil cone sprayed from the nozzle from spraying into the vortex plate; effectively adjust the ratio of gasoline and diesel to gas, so that the gasoline and diesel increase the mass conversion law slowly, or the gas increase the mass conversion law quickly; promptly remove the carbon deposits and coke around the nozzle to prevent the flame from deflecting; heavy residual oil contains more residues, which can easily cause serious damage to the high-pressure oil pump and increase the working pressure, affecting the actual effect of atomization and the shape of the flame, so the high-pressure oil pump must be repaired or replaced in time; install metal filter devices in front of the first and second high-pressure oil pumps, and clean them frequently to prevent the residues in the gasoline and diesel from blocking the nozzle.
The operators should be trained in professional skills on a regular basis to strengthen their job responsibilities and moral education, so that they can establish their respective job responsibilities, understand the importance of their positions, understand the content of their work, and improve their professional level. Skilled operators can properly control the temperature of the asphalt mixing plant mixture to avoid gasoline and diesel waste.
In order to improve the combustion-supporting effect and effectively reduce the operating costs of asphalt mixing stations, Sinoroader Group kindly reminds that the following issues should be noted when using the burner in the asphalt mixing station: To improve the maintenance of the burner, the burner nozzle should be cleaned of charred materials and carbon deposits on the ignition electrode regularly. The nozzle can be disassembled according to the atomization status; the air-oil ratio of the burner is generally not adjusted, and the fuel pump pressure can be adjusted according to the smoke status and the temperature of the asphalt mixture; the sulfur dioxide generated by the combustion of light fuel oil has a strong corrosion to the bag, so the bag should be maintained regularly and the air pressure changes in the bag should be paid close attention to; water deashing will produce more foam, causing the sand settling tank to flow out, so the sand settling tank should be cleaned in time, and a watering design should be carried out to settle the foam; when the steam pressure decreases or the gear oil pump noise increases, the gear oil pump must be replaced.
When the burner is started, the fuel oil circulation system should be completed through the valve, and then the burner control box should be opened to start the burner. If the electronic ignition of the fuel oil fails, you can change the inlet tee and use the diesel engine for ignition. After the ignition is successful for 2 minutes, you can convert it into fuel oil. In this way, even the light fuel oil of lower quality can ensure combustion.

The mixing speed of asphalt mixing plant equipment is indeed very fast, and the corresponding mixing power must be very high, but the specific amount must be measured in a certain way to determine the scope of use of asphalt mixing equipment. There are many methods to measure the mixing power of asphalt mixing equipment, but the relatively small errors are the motor counter-torque measurement method and the strain measurement method.
When the motor of the asphalt mixing equipment starts running, the electromagnetic moment acting on the motor rotor and the electromagnetic moment acting on the motor stator are equal, but their directions are opposite. Therefore, as long as the torque acting on the stator is measured, the torque on the rotor can be obtained, and the actual mixing torque is obtained after deducting the friction torque on the rotor bearing.
On the premise of knowing the torque and mixing speed, the mixing power of the asphalt mixing equipment can be calculated. This is the so-called motor counter-torque measurement method, which is relatively simple and suitable for smaller mixing systems.

When an ordinary asphalt mixing station completes the mixing operation, it will cause great pollution to the surrounding environment. In order to solve this problem, environmentally friendly asphalt mixing equipment came into being. What are the characteristics of this type of equipment?

Asphalt mixing plants are highly professional equipment with complex systems. It is inevitable that some failures will occur during use. So, what are the common hardware failures of asphalt mixing plants? Do you know?
(I) Because its system is relatively complex, when different components have problems, the problems caused may be different. If during the operation, it is found that the material addition of each silo is inaccurate, this problem may be due to the failure of the sensor of the asphalt mixing plant. At this time, the machine should be stopped for inspection and replaced with a new sensor if necessary. It may also be caused by the jamming of the scale bar. At this time, foreign objects should be removed in time.

Asphalt mixing plant is a very practical engineering machinery. Especially in the road construction process, it plays an irreplaceable role. Due to its importance, in addition to ensuring its own quality, the use and maintenance of the equipment must be carried out normally. Let’s learn about the daily maintenance requirements of asphalt mixing plants.

Judging from the current situation of domestic highway construction, asphalt mixing stations will also achieve great development for a long time to come. This is also a result of rapid economic development. However, we have found that more and more quality problems occur when constructing asphalt pavements in modern times. Therefore, we have to put forward more stringent requirements for the quality of asphalt.

Asphalt mixing stations play an important role in road construction. This article starts from the site selection, commissioning, and acceptance of the asphalt mixing plant, and elaborates on comprehensive and reasonable planning to avoid disturbing the normal construction order.

The quality of the asphalt mixing plant will be a key factor affecting the quality of the project. After reviewing relevant materials related to the production and construction of asphalt concrete, we summarized some cases of failures in asphalt concrete mixing stations during construction and analyzed the reasons.
1. Unstable output and low production efficiency of asphalt mixing plants
(1) Improper proportioning. The mix ratio of asphalt concrete is divided into target mix ratio and production mix ratio. Among them, the target mix ratio controls the cold material transportation ratio of sand and gravel materials, and the production mix ratio is the mixing ratio of various types of sand and stone materials in the finished asphalt concrete materials specified in the design. The production mix ratio is determined by the laboratory, which directly determines the off-site grading standard of the finished asphalt concrete. The target mix ratio is set to further ensure the production mix ratio, and can be adjusted appropriately during production according to the actual situation. When the target mix ratio or the production mix ratio is not appropriate, the stones stored in each measurement of the asphalt mixing station will be disproportionate, with some overflowing and some other materials, unable to be weighed in time, and the mixing cylinder will be idling, resulting in reduced output.

Asphalt mixing plant refers to a complete set of equipment used for batch production of asphalt concrete. Its main function is to produce asphalt mixture, colored asphalt mixture, etc., and has been widely used in road construction. However, during the production process of asphalt mixture, pollutants such as noise, dust, and asphalt smoke will be produced, seriously polluting the environment and threatening the health of workers. Therefore, under the current background of building a resource-saving and environment-friendly society in our country, it is very important to save energy and reduce consumption during the use of asphalt mixing plants. The following article mainly starts from the three factors that affect the asphalt mixing plant, and explores the energy saving and consumption reduction measures of the asphalt mixing plant, aiming to reduce the cost of asphalt production and improve the efficiency of the asphalt plant.

The asphalt mixing plant is constructed according to a certain process, which can not only ensure the construction quality, but also ensure that the asphalt mixing plant is not damaged. Although the construction details are critical, the key skills of the asphalt mixing plant construction must be mastered.
Before the construction of the asphalt mixing plant, the top surface of the asphalt mixing plant construction range should be removed, and the dry and flat site elevation should be kept to meet the design requirements. If the ground surface is too soft, the foundation should be reinforced to prevent the construction machinery from becoming unstable and to ensure that the pile frame is vertical.

1.During the operation of asphalt mixing station equipment, in addition to ensuring that the asphalt mixing station equipment is in good condition, it should also be equipped with a mineral moisture content detector and a finished material tester, and the relevant data should be frequently tested for the operator to adjust the operation in time, so as to keep the equipment in good condition.
2. In addition to affecting production capacity, the moisture content of mineral materials is also the main factor that determines fuel consumption. Additional material sheds should be added.
3. Before operation, all working parts and devices of the asphalt mixing station equipment should be fully checked to see if they are intact and normal. If there is a problem, it must be properly handled before operation, and it is forbidden to operate with illness.

The driving device is one of the important components of the asphalt mixing plant, so whether it can operate reliably must be highly valued to avoid adverse effects on the entire asphalt mixing plant. In order to ensure that the driving device in the asphalt mixing plant is indeed complete and reliable, the following maintenance measures are essential.

1: The site should be located on higher ground and away from residential areas and densely populated areas.
Because part of the equipment of the mixing station is installed below the ground, in order to avoid continuous rainfall. The equipment will suffer disaster, and the changing aggregate moisture content will affect the concrete quality. Quality accidents are prone to occur. Therefore, during site construction, attention should be paid to the construction of drainage pipelines and sand and gravel quarries. With the rapid development of cities. With the continuous expansion of urban scale, environmental protection requirements will become more and more stringent. Urban roads prohibit gravel vehicles from passing, so concrete mixing plants should be built far away from urban areas.

Asphalt (composition: asphaltenes and resin) tanks are divided into: intermittent and continuous functions according to the production process: initial batching of aggregates, heating and drying, screening and measurement; heating and insulation of asphalt (composition: asphaltene and resin) , transportation and measurement; transportation and measurement of filler; uniformly mix the measured aggregate, asphalt (composition: asphaltene and resin), and filler into a finished product of a certain temperature.

Current highway projects are generally large-investment projects. When carrying out actual project construction, it is very necessary to control the cost of the project. The production cost control and management of asphalt mixing stations in highway projects plays a huge role in controlling the cost of the entire highway project, because the main expenses of highway projects are concentrated on the mixing stations, and almost all the equipment used in highway projects Materials are closely related to the mixing station.

Asphalt mixing stations and equipment must implement secondary leakage protection measures. They can only be used after being plugged in and operated through the circuit breaker before use. During the trial operation, it is necessary to verify that the rotational speed of the mixing drum will be inappropriate.

There is also a reversing valve in the asphalt mixing plant, which generally does not cause problems, so I have not understood its solutions in detail before. But in actual use, we encountered this kind of failure. How should we deal with it?
The failure of the reversing valve of the asphalt mixing station is not complicated, that is, the reversing is not timely, gas leakage, electromagnetic pilot valve failure, etc. The corresponding causes and solutions are of course different. For the reversing valve to not change direction in time, it is generally caused by poor lubrication, the spring is stuck or damaged, oil dirt or impurities get stuck in the sliding part, etc. For this, it is necessary to check the status of the lubricator and the quality of the lubricating oil. Viscosity, if necessary, the lubricant or other parts can be replaced.
After long-term use, the reversing valve is prone to wear of the valve core sealing ring, damage to the valve stem and valve seat, resulting in gas leakage in the valve. At this time, the sealing ring, valve stem and valve seat should be replaced, or the reversing valve should be replaced directly. In order to reduce the failure rate of asphalt mixers, maintenance must be strengthened on a daily basis.

Synchronous gravel sealing in road maintenance can quickly improve road driving performance, repair anti-skid performance, smoothness, etc. It is used in preventive maintenance and is also one of the methods of low-grade road pavement construction. Synchronous gravel seal has the advantages of high strength, rough surface, non-slip, impermeable, good durability, and prevention of water mist when driving on rainy days. The so-called synchronous gravel sealing layer is to use special equipment, namely the synchronous gravel sealing truck and the bonding material (modified asphalt or modified emulsified asphalt) to be spread simultaneously on the road surface, and the single layer of asphalt wear is formed by natural driving or rolling with a road roller. layer, mainly used as asphalt surface layer.

Mechanism to avoid asphalt damage in asphalt mixing plant
1. Asphalt operators should undergo physical examination. Anyone suffering from conjunctivitis, skin disease or allergic reaction to asphalt should not engage in asphalt work.
2. Asphalt operators must apply protective ointment on exposed parts of their skin, and a first aid kit should be provided on the construction site.
3. The factory uniforms and protective equipment of asphalt operators are stored in a centralized manner and are prohibited from being worn home or entering collective dormitories.
4. The transfer of lumpy asphalt should usually be carried out at night and on cloudy days, especially during hot seasons. Small machinery should be used for loading and unloading, and it should not be lifted and transported directly by hand.

The drying and heating system of the asphalt mixing plant can be regarded as an important part of the whole, so in actual work, it treats the material in a countercurrent heating manner, thereby achieving full dehydration of the cold aggregate, and heating it to a certain temperature, thereby providing the necessary conditions for the normal and continuous operation of the asphalt mixing plant.
During the entire heating process of the asphalt mixing plant, the main purpose is to make the performance of the mixture more in line with the requirements of use, and to make the finished material have good paving performance. Under normal circumstances, the heating temperature of the aggregate is about 160℃-180℃.

Asphalt flue gas treatment methods, their principles and characteristics, and an asphalt flue gas environmental protection treatment plan based on the actual asphalt flue gas problems faced by the unit.

1. Basic situation
My unit’s mixing plant is equipped with a 4000-type asphalt mixing plant. During daily production of the asphalt mixing plant, a large amount of asphalt smoke will be emitted from the mixing pot discharge port. This smoke not only has an unpleasant smell, but also contains A large number of compounds that are harmful to the human body, such as benzopyrene, benzanthracene, carbazole and other polycyclic aromatic hydrocarbons, mostly have carcinogenic risks. Smoke overflow will cause pollution to the surrounding atmospheric environment and affect the personal health of workers. Although the overflow port of the mixing station is equipped with a dust retaining wall, the fine dust is seriously raised, and the cold material belt conveyor is dusty. In order to protect the environment, reduce pollution, and reduce cost investment, based on full research and absorption of technology in the same industry, and combined with the actual situation of asphalt mixing, we are planning to install asphalt mixing bag dust collectors to the flue at the discharge port of the mixing pot to control asphalt fumes. Gas is processed. The dust removal efficiency of the bag dust collector can reach 97%~99%, and the dust-containing gas can be purified to a level of 50mg/Nm3.

Asphalt concrete mixing equipment generally uses conveyor belt conveyors to transport cold materials. Its main advantages are large conveying capacity, continuous operation, simple equipment structure and automatic control. However, belt deviation is a common fault, which directly affects the drying operation of the drying drum and also affects the production efficiency of the mixing equipment. Therefore, it is very important for the asphalt mixing station to solve the belt deviation problem at the operation site of the asphalt concrete mixing equipment.

The mobile forced asphalt mixing equipment adopts intermittent drying cylinder, double forced mixer, the main machine can be towed, small footprint, short installation cycle, convenient operation and maintenance, good stability, high degree of automation, high degree of standardization, and high quality of finished products, and the technology of continuous improvement. The mobile forced asphalt mixing plant is suitable for high-grade road asphalt paving and maintenance.
1. The combined structure of the drum dryer and the batching machine is installed on a movable bracket for easy movement.
2. The asphalt mixing plant is equipped with a double horizontal shaft to boil the aggregate and ensure uniform mixing.
3. In the densely arranged hanging barrels, the hot aggregate rises vertically. This lifting tool is easy to use and reliable.
4. For accurate weighing of aggregates, asphalt and powder ore, a measuring scale is used, which contains a weighing sensor for electronic measurement.
5. The movement of the power material follows a closed spiral path, which ensures little material loss and provides safe transfer.
6. On the cyclone burner, high-pressure oil is sprayed out and quickly atomized. In the combustion chamber, the material is fed in a spiral manner and automatically ignited by the oil mist, which ensures combustion efficiency. The cylindrical barrel of the burner is separated from the burner head. The furnace cavity can be pushed in and pulled out, which is convenient for replacing the damaged side column bricks inside the burner. The entire burner has a large heat capacity and high thermal strength. This is cost-effectiveness.

The asphalt mixing equipment mentioned here may also refer to an asphalt concrete mixing plant. At present, asphalt mixing equipment generally uses a complete set of equipment for mixing. So what are the benefits of using a complete set of equipment?
1. More effective.
In today’s industrial production, a complete set of asphalt mixing equipment can help improve production efficiency and ensure product quality. This is why even in a mixing plant, the equipment used is a complete set of equipment.
2. Ensure quality.
When mixing asphalt, a certain ratio is set. For this type of asphalt liquid used in different occasions, its ratio control has strict requirements. It is necessary to determine its mixing method and mixing time to ensure that the asphalt liquid is consistent with the production site. One of the advantages of a mixing plant is that the quality can be effectively controlled.
3. It can be sampled.
After mixing at the mixing plant, the quality inspector can sample and inspect to ensure that the mixed asphalt liquid meets the use requirements.
In short, asphalt mixing equipment will use a complete set of equipment, mainly to facilitate the later asphalt to meet production needs. Through the mixing plant, the mixing time and feeding sequence can be better controlled, so that the mixed product can meet different use requirements. And after using the archiving equipment, effective spot checks can be carried out, which can better ensure that the quality meets the construction requirements.

Oscillating screen. It can screen the heated aggregate according to the design. It requires fully enclosed, double oscillating motor replacement (replacing one substance for another (mostly the strong one takes the place of the weak)) eccentric shaft oscillation, each The layer screen is easy to install quickly. The service life of the drying roller and the power part is not less than 6000h. The roller can fully use heat, the material curtain flows evenly, and the inclination is required to be adjustable.

Road construction machinery is a large range, so let’s talk about one of it, which is the asphalt mixing plant. It is mainly used to produce asphalt, so it is very important among road construction machinery and equipment. An important part, if the quality of the finished product is not good, it will greatly affect the quality of the road. Therefore, below, the editor will use the form of question and answer to guide you to continue learning.

In order to keep the asphalt mixing plant in a stable operating process, a series of adverse factors related to it must be excluded. What should be paid attention to in this process?
First of all, the selection of the delivery pump in the asphalt mixing plant must meet the requirements of asphalt pouring per unit time during construction, height, and horizontal distance requirements. At the same time, there must be a certain technical and production capacity reserve, and the balanced production capacity is preferably 1.2 to 1.5 times.
Secondly, the movement and hydraulic systems of the asphalt mixing plant must be normal, and there must be no abnormal sound and vibration to avoid large aggregates and lumps inside the equipment, otherwise it is easy to get stuck at the feed inlet of the mixing plant or be blocked due to arching. Another point is that when the asphalt mixing plant is in the same site, it is not suitable to use too many pumps and pumps from multiple manufacturers to avoid affecting its normal operation.

As a special equipment, standardizing the operating procedures of important production tools of asphalt mixing stations, conducting daily maintenance, regular inspections, eliminating hidden dangers, etc. can effectively ensure the safety and stability of the equipment and prevent equipment from malfunctioning due to misoperation. causing equipment damage. Good maintenance operations can also greatly extend the service life of asphalt mixing plants. Therefore, before daily operation, the asphalt mixing plant must be properly maintained to make the asphalt mixing plant operate better and create wealth.
